DIE-PRESS

Die Press calculates the radial and tangential stresses in the inserts and casing in a press-fit die assembly. It determines the optimum interference between the inserts and casing to allow the required pressure for that application. For a 2/3 ring die assembly, it determines their dimensions that would allow the dies to take the maximum internal pressure.

The “Die-Press Calculator” has been developed for tool designers and engineers in the metal forming field including cold forging, hot forging, extrusion and press fitting applications.

Beneficial for tool designers, engineers and operators designing the tooling layout, number of inserts and press fit amount

Various Applications of this calculator Cold Forging Tooling, Hot forging tooling, Extrusion Tooling, Press fitting of components. Any application where the tool has to withstand high internal pressure.

RESULT - STRESSES

Determine radial and tangential stresses in one ring, two ring and three ring die assemblies with press fit and internal forging pressure.

RESULTS - OPTIMAL INTERFERENCE

Determines the optimum interference to withstand internal pressure in a two ring and a three ring die assembly

OPTIMUM DIMENSIONS

Determine the optimum dimensions of insert outside diameter in Two ring assembly for given insert bore and outside diameter of casing

OPTIMUM DIMENSIONS

Determine the optimum dimensions of insert outside diameter and mid insert diameters in a Three ring assembly for given insert bore and casing outside diameter

WF-OPTIMIZER

Optimize assembly operator's work-path and layout using WF-Optimizer software

WF-Optimizer software helps the user quickly setup and optimize the operator’s station in an assembly line environment.

Within minutes, the station designer can tabulate the operator’s process, layout and assembly line information.

Using this data, the WF-Optimizer software generates the optimal layout with the corrected times and operator work flow paths.

EASY INPUT

Excel based inputs.

Easy to use, save and transfer

QUICK RESULTS

Quickly view the operator's work paths with updated times, flow, distance and discrepancies

OPTIMIZED RESULTS

Let the program optimize the layout or use the manual feature to optimize it yourself

CAD OUTPUTS

2D CAD outputs of all operations with operator workpaths for each option.

NAGLOCATE

software to determine the most efficient location of objects within the constraints imposed by the User

NESTING

Placement of a given number of blocks within a specified space. The blocks and the space can be 2 dimensional or 3 – dimensional.

PACKING

Determine the minimum dimensions of the box in which a given number of blocks can be placed. NAGLOCATE gives the minimum size and also all the arrangements of the blocks in the box.

BIN LOADING

For given number of groups of 3D blocks, NAGLOCATE determines the number of bins required and the arrangement of 3D block groups within the bins

FACILITY LAYOUT

Location of different departments of a factory where the constraint is the cost of travel between departments. NAGLOCATE determines a number of arrangements that give the least cost of travel.
